Derale Parts


Showing 1 - 10 of 34 products
SKU
Product
Rating
Price

Derale
  • Adjustable Electric Fan Controller; 3/8in. NPT Thread In Probe
  • Adjustable; w/3/8 in. NPT Thread In Probe; Maximum Draw Of 25 Amps
  • Adjustable turn-on temperature from 150-240deg.F; Turn-off temperature is preset at 10deg.F below turn-on temperature; Thread in 3/8in. NPT probe; Heavy duty 40/60 amp relay maximum 25 amp continuous draw; AC override circuit included
  • Electric Fan Controller
  • Features:
    • Adjustable Turn-On Temperature From 150 To 240 Degrees Fahrenheit
    • 10 Degrees Lower Turn-Off Temperature Than Turn-On Temperature
    • Thread in 3/8 in. NPT Temperature Sensor
    • Heavy Duty 40/60 Amp Relay
    • Includes AC Override Circuit
    • Ground Circuit Relay
    • Replacement 3/8 in. NPT Sensor Part Number 16750
  • This newly redesigned adjustable electric fan control kit is designed to activate up to 2 fans with a total maximum draw of 25 amps. Includes a water jacket 3/8 in. NPT thread-in probe, relay wire harness and electrical connectors for an easy installation. A/C override circuit included. Adjustable fan controller turn-on range from 150°F - 240°F, and turn-off preset at 10°F lower than turn-on.

Additional Fitment Information:
Vehicle
2000 - Dodge Avenger

Derale
  • 14in. High Output Single RAD Pusher/Puller Fan with Standard Mount Kit
  • w/Standard Mount Kit; 22/16.2 Amp Draw High/Low; 14-1/2 in. Width; 14-1/2 in. Height; 2-5/8 in. Depth; 8-3/4 in. x 13-1/4 in. Mounting; Single
  • 14in. High Output Electric Fan; Std Kit
  • Radiator Pusher/Puller Fan
  • Product Attributes:
    • Diameter (in.): 14.000 In.
  • Features:
    • Mounts As Pusher Or Puller w/out Flipping Blade
    • State-Of-The-Art Symmetrical Design
    • High Output 300 Watt Motor
    • 2100 CFM On High Speed/1500 CFM On Low Speed
  • A very popular primary cooling fan, this 14 in. High Output Single RAD fan is a self-shrouded, symmetrical design with four molded mounting points. Motivated by a 2-speed 265 watt Bosch motor driving 11 patented skewed blades, it can be used as a pusher or puller fan by simply flipping brackets without changing direction of the unit. Moves up to 2100 CFM while drawing up to 22 amps.

Additional Fitment Information:
Vehicle
1990 - Dodge Grand Caravan

Derale
  • 4 Pass 17in. Series 7000 Copper/Aluminum Transmission Cooler Kit
  • Copper Tube And Aluminum Fin; 16-5/8 in. Width; 5-1/8 in. Height; 3/4 in. Depth; 11/32 in. Hose Size; 4 ft. Hose Length
  • Transmission Cooler; Compact (Carton)
  • Series 7000 Transmission Cooler Kit
  • Product Attributes:
    • Gross Vehicle Weight: 14000 Lbs.
  • Features:
    • Prevents Heat Related Transmission Failures
    • Extends Life Of Transmission
    • Improves Transmission Performance
    • Extruded Plastic Cooling Fin Guards
    • 4 Pass Cooler Design
    • 1/2 in. Copper Tubing Expanded Into Aluminum Cooling Fins
    • 11/32 in. Hose Barb Inlets
    • Rated At 14000 GVW
    • Includes Complete Hardware Kit
  • This Tube & Fin transmission cooler features 1/2 in. copper tubing expanded into aluminum cooling fins and include embossed turbulators which serve to agitate fluid for maximum heat transfer. Perfect for today's highly-stressed compact cars and SUVs', they improve shifting performance and extend the life of the transmission by eliminating heat-related transmission failures. This kit comes with a complete transmission cooler hardware kit to easily install onto vehicles with 5/16 in. transmission cooler lines.

Additional Fitment Information:
Vehicle Sub Model
1966 - Ford Falcon Base

Derale
  • High Amperage Adjustable Dual Electric Fan Controller; 3/8in. NPT Thread In Prob
  • High Amperage; Adjustable; w/3/8 in. NPT Thread In Probe; 35 Amp Per Fan; 2-3/8 in. Width; 4-5/8 in. Length; 1-9/16 in. Height; Dual
  • Hi-Amp Adjst. Dual Fan Control (3/8in. NPT)
  • Electric Fan Controller
  • Features:
    • Adjustable Turn-On Temperature From 160 To 240 Degrees Fahrenheit
    • Rated At Maximum 35 Amps Per Fan
    • Activates Fan 1 At Adjusted Temperature
    • Activates Fan 2 At 10 Degrees Fahrenheit Warmer Than Fan 1
    • 15 Degrees Lower Turn-Off Temperature Than Turn-On Temperature
    • Die Cast Aluminum Housing
    • Includes AC Override Circuit
    • Thread-In 3/8 in. NPT Probe
  • Designed with quality and performance in mind, this High Amperage Dual Fan Controller breaks new ground in the industry of electric fan controllers. 100% USA made, a bulletproof design, 35 amp per fan amperage rating, adjustability from 150°-240°F, and a die cast bright finish aluminum cap, come together to make this dual fan controller stand out from the crowd. It's capable of controlling two separate 35 amp fans at different turn-on temperatures, with only a single probe. The first electric fan will be activated at the temperature set by the user followed by the second electric fan when the temperature becomes 10°F warmer. Each electric fan will turn off at 10°F below its turn-on temperature. Kit comes complete with wiring harness, fusible link, all necessary electrical connectors and 3/8 in. NPT thread-in probe.

Additional Fitment Information:
Vehicle
1975 - Pontiac Bonneville

Derale
  • 16in. Tornado Electric Puller Fan; Standard Mounting Kit
  • 2175 CFM; 16 in. Fan Size; 3/4-16 in. Width; 14-1/2 in. x 9-3/4 in. Mounting; 15-3/4 in. Height; 1-3/4 in. Depth; 18.4 Amp Draw
  • 16in. Tornado Electric Fan; Standard Kit
  • Tornado Electric Puller Fan
  • Product Attributes:
    • Diameter (in.): 16.000 In.
  • Features:
    • Reliable/Efficient/High Torque Motors
    • 2175 CFM
    • Reversible Design/Can Be Used As Pusher Or Puller
    • Includes Nylon Mounting Kit
  • Our top of the line 16 in. Tornado fan uses 8 skewed blades, producing a healthy 2175 CFM at 0 static pressure, drawing only 18.4 amps from its quiet, high torque 225 watt motor. Includes mounting kit and illustrated installation instructions.

Additional Fitment Information:
Vehicle Sub Model
1991 - Dodge Spirit Base

Derale
  • 1in. Aluminum Belt Fan Spacer
  • Aluminum Spacer Construction; Clear Anodize Color; 1 in. Length; 5/8 in. Male Pilot Diameter; 5/8 in. Or 3/4 in. Female Plot Diameter
  • Fan Spacer; 1in. (Female 5/8-3/4 pilot)
  • Belt Fan Spacer
  • Features:
    • Aluminum Construction
    • Anodized Clear Finish
    • 1 in. Length w/5/8 in. Or 3/4 in. Female Pilot
    • Includes Fine And Course 5/16 in. Thread Hardware
    • Fan Should Have Minimum Clearance Of 3/4 in. From The Radiator
  • This 1 in. belt driven fan spacer comes with a clear anodized finish and is designed to fit most domestic 5/8 in. or 3/4 in. pilot water pumps.

Additional Fitment Information:
Vehicle
1972 - Ford Custom 500

Derale
  • 18in. High Performance Stainless Steel Standard Rotation Flex Fan; Black Hub
  • Stainless Steel; Black Hub; 18-1/4 in. Diameter; 1-3/4 in./2-1/4 in. Flange Bolt Spacing; 1-1/4 in. Depth; 50 Degrees Blade Pitch; Standard Rotation
  • 18in. HP Stnless Steel Flex Fan (Black Hub)
  • High Performance Flex Fan
  • Features:
    • Stainless Steel Fan Blades
    • Black Powder Coated Hub
    • Rated Up To 8.000 Revolutions Per Minute
    • 18 in. Standard Rotation Flex Fan Design
  • Our 18 in. high performance, standard rotation flex fan features 6 stainless steel blades and a black powder coated hub and is rated for engine speeds up to 8,000 rpm. Great for applications where space is at a premium.

Additional Fitment Information:
Vehicle
1990 - Dodge W150

Derale
  • 6 Pass 17in. Series 7000 Copper/Aluminum Transmission Cooler Kit; Intermediate
  • Copper Tube And Aluminum Fin; 16-5/8 in. Width; 7-5/8 in. Height; 3/4 in. Depth; 11/32 in. Hose Size; 4 ft. Hose Length
  • Transmission Cooler; Intermediate (Carton)
  • Series 7000 Transmission Cooler Kit
  • Product Attributes:
    • Gross Vehicle Weight: 18500 Lbs.
  • Features:
    • Prevents Heat Related Transmission Failures
    • Extends Life Of Transmission
    • Improves Transmission Performance
    • Extruded Plastic Cooling Fin Guards
    • 6 Pass Cooler Design
    • 1/2 in. Copper Tubing Expanded Into Aluminum Cooling Fins
    • 11/32 in. Hose Barb Inlets
    • Rated At 18500 GVW
    • Includes Complete Hardware Kit
  • This Tube & Fin transmission cooler features 1/2 in. copper tubing expanded into aluminum cooling fins and includes embossed turbulators which serve to agitate fluid for maximum heat transfer. Perfect for medium-sized cars and compact trucks and SUVs' that see light duty towing, they improve shifting performance and extend the life of the transmission by eliminating heat-related transmission failures. This kit comes with a complete transmission cooler hardware kit to easily install onto vehicles with 5/16 in. transmission cooler lines.

Additional Fitment Information:
Vehicle
1996 - Mercury Cougar

Derale
  • 16 Pass Electra-Cool Remote Fluid Cooler;-6AN
  • 16 Pass Tube And Fin Cooler Style; 15-3/4 in. Width.; 14-3/4 in. x 5-1/4 in. Mounting; 11-1/2 in. Height; 5 in. Depth; 8-3/4 in. Inlet Dim
  • 16-Pass Electra-Cool Cooler (-6AN)
  • Electra-Cool Remote Cooler
  • Features:
    • Mounts Anywhere Space Permits
    • Electric Fan Supplies Optimum Airflow
    • Dramatically Extends Engine And Transmission Life
    • 16 Pass Tube And Fin Cooler
    • Clear Anodized Aluminum Shroud
    • 650 CFM Reversible Tornado Electric Fan
    • -6AN Inlet Size
    • Rated At 250 PSI Working Pressure/300 PSI Burst Strength
    • Cooler Assembly Includes Fan Mounted Cooler
    • Cooler Assembly Includes Two Aluminum -6AN Fittings
    • Cooler Assembly Includes Two -6AN x 3/8 in. Hose Barb Fittings
  • With its own air supply available when needed, the Electra-Cool is one of our most popular remote coolers and can literally be mounted anywhere space permits, making it a popular addition for performance compacts, hot rods, muscle cars and trucks. An efficient 16-pass tube and fin cooler coupled with a powerful 10 in. diameter Tornado fan and aluminum brackets, and featuring -6AN male fittings, each unit also includes 2 each -6AN x 3/8 in. barb fittings. Designed for transmission, power steering and fuel cooling.

Additional Fitment Information:
Vehicle Sub Model
2017 - GMC Canyon Denali

Derale
  • 12in. Tornado Electric Puller Fan; Standard Mounting Kit
  • 880 CFM; 12 in. Fan Size; 12-3/8 in. Width; 11-1/4 in. x 5-1/4 in. Mounting; 11-13/16 in. Height; 1-1/4 in. Depth; 8.8 Amp Draw
  • 12in. Tornado Electric Fan; Standard Kit
  • Tornado Electric Puller Fan
  • Product Attributes:
    • Diameter (in.): 12.000 In.
  • Features:
    • Reliable/Efficient/High Torque Motors
    • 880 CFM
    • Reversible Design/Can Be Used As Pusher Or Puller
    • Includes Nylon Mounting Kit
  • This 12 in. reversible Tornado fan uses 8 skewed blades, producing 880 CFM at 0 static pressure, drawing only 8.8 amps. Take two of these fans and one of our 16701 Dual fan mounting brackets and you have a powerful dual fan combo in a compact package. Includes mounting kit and illustrated installation instructions.

Additional Fitment Information:
Vehicle
1991 - Mercury Topaz
Showing 1 - 10 of 34 products
